Specifications
- Manufacturer: Husqvarna
- Model: 535LS
- Type: String Trimmers
- Equivalent vibration level (ahv, eq) front handle: 4.7 m/s²
- Equivalent vibration level (ahv, eq) rear handle: 6.6 m/s²
- Cutting width: 50 cm
- Weight (excl. cutting equipment): 5.5 kg
- Product size length: 179.3 cm
- Tube length: 1,483 mm
- Tube diameter: 24 mm
- Exhaust emissions (CO average): 418.31 g/kWh
- Exhaust emissions (CO average): 243.69 g/kWh
- Exhaust emissions (CO average): 243.69 g/kWh
- Cylinder displacement: 34.6 cm³
- Power output: 1.6 kW
- Maximum power speed: 8,400 rpm
- Fuel tank volume: 0.6 l
- Fuel consumption: 475 g/kWh
- Fuel consumption: 0.99 kg/h
- Idling speed: 2,900 rpm
- Spark Plug: Champion RCJ6Y
- Electrode gap: 0.5 mm
- Torque, max. at rpm: 6,600 rpm
- Torque, max.: 1.9 Nm
- Clutch engagement speed (±120): 4,300 rpm
- Maximum rpm output shaft: 8,220 rpm
- Harness: Single harness
- Trimmer head: T35X M10
- Lubricant type (Engine): Husqvarna 2 stroke or equiv. at 50:1
- Sound pressure level at operators ear: 100 dB(A)
- Sound power level, guaranteed (LWA): 116 dB(A)
- Gear ratio: 1.29
- Drive gear angle: 30 °
