Specifications
- Manufacturer: Husqvarna
- Model: 565
- Type: Chainsaws
- Power output: 3.7 kW
- Cylinder displacement: 70.6 cm³
- Maximum power speed: 9,300 rpm
- Idling speed: 2,700 rpm
- Torque, max.: 4.2 Nm
- Torque, max. at rpm: 6,900 rpm
- Clutch engagement speed (±120): 3,800 rpm
- Fuel consumption: 442 g/kWh
- Fuel consumption: 1.63 kg/h
- Spark Plug: NGK BPMR7A
- Electrode gap: 0.5 mm
- Ignition module air gap: 0.3 mm
- Oil pump type: Adjustable flow, no flow at idle
- Exhaust emissions (CO2 EU V): 804 g/kWh
- Bar length (inch): 16 in
- Recommended bar length, min: 38 cm
- Recommended bar length, max: 70 cm
- Chain type: C83
- Gauge: 1.3 mm
- Pitch: 3/8"
- Sprocket type: Rim 7
- Weight (excl. cutting equipment): 6.5 kg
- Lubricant type (Engine): Husqvarna 2 stroke or equiv. at 50:1
- Oil tank volume: 0.7 US pint
- Oil tank volume: 0.35 l
- Sound power level, guaranteed (LWA): 119 dB(A)
- Sound power level, measured: 117 dB(A)
- Sound pressure level at operators ear: 105 dB(A)
- Equivalent vibration level (ahv, eq) front handle: 5.2 m/s²
- Equivalent vibration level (ahv, eq) rear handle: 5.3 m/s²
