Specifications
- Manufacturer: Arctic Cat
- Model: ZR 200
- Year: 2025
- Type: Youth
- Engine Type: 200, 4-Stroke
- Displacement: 192cc
- Cooling: Air
- Cylinders: 1
- Bore x Stroke: 70 x 50 mm
- Lubrication: Oil Sump
- Ignition: CDI
- Engine Stator Output: 96W @ 3000 RPM
- Fuel Delivery: BS-25 Carburetor
- Exhaust: Muffler
- Fuel Capacity: 2.2 gal
- Oil System Capacity: 0.6 qt
- Coolant System Capacity: N/A
- Minimum Octane: 87
- Drive Clutch: Arctic 5.25 in Diameter (RPM Sensing)
- Driven Clutch: Arctic 6.75 in Diameter (Roller Cam)
- Drive System: Arctic 200 Drive System
- Brakes: Hydraulic Brake/Disc on Driveshaft
- Clutch Calibration: 0-5,000 ft
- Gearing: N/A
- Chain Pitch: N/A
- Track Drive Sprocket: 5 Tooth, 2.59 Pitch, Exvolute
- Reverse: N/A
- Front Suspension: AWS
- Ski Shocks: Hydraulic Twin Tube
- Sway Bar: N/A
- Front Travel: 4.5 in
- Rear Suspension: Slide-Rail, Adjustable Torsion Spring & Coil-Over Rear Shock
- Front Track Shock: N/A
- Rear Track Shock: Hydraulic Twin Tube
- Rear Travel: 8.5 in
- Overall Chassis Length: 84 in
- Overall Chassis Width: 35-37 in
- Overall Chassis Height: 36 in
- Track Type: Cobra
- Track Width: 10 in
- Track Length: 93 in
- Lug: 1.00 in
- Pitch: 2.59 in
- Ski Stance: 29.5-31.5 in - Adjustable
- Ski Type/Width: Youth - 5 in
- Runner Type: Single Runner
- Type of Gauge: N/A
- Speedometer: N/A
- Tachometer: N/A
- Odometer: N/A
- Fuel: N/A
- Oil: N/A
- Coolant: N/A
- Clock: N/A
- Battery Voltage: N/A
- Altimeter: N/A
- Hours: N/A
- Color: Black/Medium Green
- Heat Exchanger: N/A
- Starter: Turnkey Electric Start
- Handlebars: Straight
- Lighting: Halogen 1-Bulb
- Seating: Youth 200
- Standard Accessories: Hand Warmers, Tether Switch, Standard Steering, Standard Brake Disc, Youth Front Bumper
- Windshield: 4 in Low Height
